Cannot Change Direction-LHSR

Machine Skates cannot Change Direction Max Load:6-36 ton
Brand:LONGSHENG®
Warranty: 6 months

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Machine Skates cannot Change Direction

LHSR-U Machine Skates (Roller Skids) is a kind of going straight Machine Skates,which just can go straight and have a turntable above it. On the turntable there are many  screwed hole, via this hole can fixed with the equipment which you want to move.

The structure of this kind of Machine Skates is simple, easy to handle and safely.

LHSR-U Machine Skates (roller skids) can combined with steerable Machine Skates.

Machine Skates LHSR-U Machine Skates
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Model Max Load (T) Common Load (T) Wheel Qty (pcs) Wheel Size(mm) L(mm) W(mm) H(mm) NW(KG)
LHSR-6U 6 3 4 80x70 300 225 110 15
LHSR-8U 8 4 6 80x70 400 225 110 21
LHSR-12U 12 6 8 80x70 500 225 110 30
LHSR-15U 15 7 9 80x70 400 313 110 32
LHSR-18U 18 9 12 80x70 500 313 110 43
LHSR-24U 24 12 16 80x70 550 380 110 65
LHSR-30U 30 15 20 80x70 690 380 110 79
LHSR-36U 36 18 25 80x70 690 462 110 95
