Steerable Machine Skates-AKBK

Steerable Machine Skates-AKBK Max Load:12-84 ton
Brand:LONGSHENG®
Warranty: 12 months

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Steerable Machine Skates of  Series Kits & Sets-AKBK


The AKBK Steerable Machine Skates & Load Moving Skates (also can be called Cargo Trolley,Machinery Movers,Machine Dolly,Load Moving Skates,Moving Rollers,Machine Roller)includes AK and BK two parts.

The AK with the handle can turn direction,while the BK part with two small trolleys can not turn direction.

The AKBK Steerable Machine Skates is a kind of heavy-duty combined type Machine Skates.
Steerable Machine Skates of  Series Kits & Sets-AKBKSteerable Machine Skates-AKBK
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

Model Max Load
(T)
Common Load
(T)
Wheel Qty
(pcs)
Measurement L*W*H(mm) Loading Plate
(mm)
Wheel Size
(mm)
Wheel Material
AK6 12 8 4 330×300×145 Ф150 Ф115×60 PU rubber
BK3 2*2 290×95×145 240×80
AK12 24 16 8 530×540×145 Ф200 Ф115×60 PU rubber
BK6 4*2 290×160×145 240×140
AK18 36 24 12 660×540×145 Ф200 Ф115×60 PU rubber
BK9 6*2 290×230×145 240×140
AK24 48 32 16 850×550×145 Ф235 Ф115×60 PU rubber
BK12 8*2 290×290×145 240×140
AK30 60 40 20 975×550×145 Ф235 Ф115×60 PU rubber
BK15 10*2 385×290×145 240×235
AK36 72 48 24 1150×550×145 Ф235 Ф115×60 PU rubber
BK18 12*2 430×290×145 280×240
AK42 84 56 28 1275×550×145 Ф235 Ф115×60 PU rubber
BK21 14*2 500×290×145 280×240

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
