Double-acting Hollow Plunger Hydraulic Jack

	Rated Lifting Force:100-6000 KN
	Brand:LONGSHENG®
	Warranty: 12 months

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Double-acting Hollow Plunger Hydraulic Jack -LSJZ

1,Double-acting,hydraulic return;

2,Hollow Plunger design can be used for pulling and thrusting;

3,Equipped with a Safety Valve to prevent overpressure caused damage;

4,Paint surface for better corrosion-resistant;

5,Equipped with Dust-proof Ring reduces contamination, extending life,All models have Quick Connectors and Dust Caps;

Double-acting Hollow Plunger Hydraulic Jack

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

Model	Drawing force	Working pressure	L2	Body height L1	Stroke L	Inner Diameter	Inner Diameter	Cylinder rod diameter	Outer diameter	Pore size	L3	NW
Model	(KN)	(MPa)	(mm)	(mm)	(mm)	D1	D2(mm)	D3(mm)	D(mm)	d	(mm)	(Kg)
LSJZ100-100	100	42.5	131	224	100	65	35	50	97	19.6	39.5	11
LSJZ100-200	100	42.5	231	324	200	65	35	50	97	19.6	39.5	16
LSJZ200-100	200	63.7	141	240	100	80	49	65	112	32	42.5	15
LSJZ200-200	200	63.7	241	340	200	80	49	65	112	32	42.5	21
LSJZ300-100	300	42.2	129	227	100	110	55	85	146	40	41	23
LSJZ300-200	300	42.2	232	330	200	110	55	85	146	40	41	33
LSJZ500-100	500	48.3	148	293	100	140	80	115	180	55	57	46
LSJZ500-200	500	48.3	248	393	200	140	80	115	180	55	57	60
LSJZ1000-100	1000	59	140	257	100	170	85	136	210	65	48	54
LSJZ1000-200	1000	59	240	357	200	170	85	136	210	65	48	72
LSJZ2000-100	2000	42.8	160	330	100	296	167	243	350	137	65	177
LSJZ2000-200	2000	42.8	260	430	200	296	167	243	350	137	65	223
LSJZ3000-200	3000	45.4	275	465	200	356	206	296	424	171	75	359
LSJZ5000-200	5000	54	295	565	200	400	210	320	515	165	112.5	709
LSJZ6000-200	6000	65	295	565	200	400	210	320	515	165	112.5	709
